Solving complicated problems and creating reliable, low-maintenance systems, like with this AGOL dependency automator script.
About: This tool was inspired by a workflow developed during my time at the City of Billings, rewritten and heavily pared down for general public use with permission.
Problem: Knowing what will change if a feature class or service is updated or deleted can be very difficult, espeically in large organizations. Conversely, if a webmap or application is malfunctioning, it can be difficult to identify the underlying data for troubleshooting. Data lineage documentation that captures the entire data flow and is in an easily readable format, such as a formatted Excel Table, is extremely tedious to create manually and vulnerable to neglect. Qonda Reports provides such functionality, but is relatively expensive and cannot document at the feature class level.
Solution: This script automates the creation of dependency lineage documentation for AGOL Web Experiences. While this specific script only details the flow of data from services into webmaps into Experiences, it can be expanded to cover all AGOL/Portal applications and dig down to the feature class level, allowing the mapping of feature classes to user-facing applications.
Method: This script compiles a dictionary of all Experiences in AGOL and parses their related JSONs to extract the webmaps and services services they depend upon, which are then fed into a dictionary structured and as {experience : {webmap : [services]}}. This is then converted into a Pandas dataframe and written to a formatted Excel sheet.
from arcgis.gis import GIS
import pandas as pd
import re
import os
import datetime
import xlsxwriter as xl
import numpy as np
date = datetime.date.today()
formatted_date_mdy = date.strftime("%m_%d_%Y")
os.mkdir(fr"filepath\AGOL_Dependencies_{formatted_date_mdy}")
expitems = []
exptitle = []
expid = []
portal_url =
username =
password =
try:
gis = GIS(portal_url, username, password)
print(f"Successfully connected to {gis.properties.portalName}")
except Exception as e:
print(f"Error connecting to the portal: {e}")
exit()
web_exps = gis.content.search(query = "type:Web Experience", item_type = "Web Experience", max_items = 1000)
if web_exps:
for web_exp in web_exps:
exptitle.append(web_exp.title)
expid.append(web_exp.id)
expitems.append(web_exp)
expdict = dict(zip(exptitle, expid))
portal_item_dict = tempitemdictexp
# Defining Functions
# Creates a dictionary of experiences/dashboards and webmaps. Used on the JSONs of dashboards and experiences.
def find_web_maps(data,found_values=None):
if found_values is None:
found_values = []
if isinstance(data, dict):
if "itemId" in data:
dep_id = data.get('itemId')
if dep_id is not None:
dep_item = portal_item_dict.get(dep_id)
if dep_item:
info_str = info_str = (f"{dep_item.title}, Item ID: {dep_item.id}, {dep_item.type}")
found_values.append(info_str)
else:
print(f'Service {dep_id} does not exist')
for key, value in data.items():
find_web_maps(value, found_values)
elif isinstance(data, list):
for each in data:
find_web_maps(each, found_values)
return found_values
# Recursively searches though map dependency JSON for item IDs and rest service URLs and creates a list of dependencies.
# Used within a for loop of web maps.
def dependency_recursion(data,found_values=None):
if found_values is None:
found_values = []
if isinstance(data, dict):
if 'itemId' in data:
dep_id = data.get('itemId')
dep_item = portal_item_dict.get(dep_id)
if dep_item:
info_str = (f"{dep_item.title} || {dep_item.id} || {dep_item.type} || {dep_item.url}")
found_values.append(info_str)
else:
print(f'Service {dep_id} does not exist')
elif 'url' in data:
info_str = data.get('url')
if r'/image' not in info_str.lower() and r'/mapviewer' not in info_str.lower() and not re.fullmatch(r'[\w\W]{32,38}', info_str):
found_values.append(info_str)
for key, value in data.items():
dependency_recursion(value, found_values)
elif isinstance(data, list):
for each in data:
dependency_recursion(each, found_values)
return found_values
def make_alphabet(n):
labels = []
while len(labels) < n:
num = len(labels)
label = ""
while True:
num, rem = divmod(num, 26)
label = chr(65 + rem) + label
if num == 0:
break
num -= 1
labels.append(label)
return labels
# Xlsxwriter formatting function
def create_new_sheet(writer_object, dataframe, sheet_title, index_str):
dataframe = dataframe.fillna("")
dataframe.to_excel(writer, sheet_name = sheet_title)
sheet_id = writer.sheets[sheet_title]
headers_list = []
for each in dataframe.columns:
headers = {'header' : each}
headers_list.append(headers)
headers_list[0:0] = [{'header' : index_str}]
alphabet = make_alphabet(len(headers_list))
rowcount = dataframe.shape[0] + 1
sheet_id.add_table(f'A1:{alphabet[-1]}{rowcount}', {'columns' : headers_list})
return sheet_id
experience_dependency_dict = {}
for key in expdict:
try:
experience = portal_item_dict.get(expdict[key])
func_in = experience.get_data()
final = find_web_maps(func_in)
experience_dependency_dict[key] = final
except Exception as e:
print(f'{key}{e}')
# Creates a nested dictionary detailing all dependency levels.
# The dictionary is formatted as follows: {Experience: {Web Map: [Service]}}
exp_dependency_dict = {}
for key in experience_dependency_dict: #Looping over experiences
#Finds the dependencies of each webmap associated with each experience
try:
for webmapval in experience_dependency_dict[key]: #Looping over webmaps corresponding to each experience
innermost_dict = {}
match = re.search(r'ID:\s*([\w]+)', webmapval, re.IGNORECASE) #Uses regex matching to extract webmap itemid from the dictionary value.
idtext = match.group(1)
mapItem = portal_item_dict.get(idtext) #Finds webmap associated with the id value
dependencies = mapItem.get_data(try_json = True)['operationalLayers'] #returns a dictionary with details on supporting services. try_json is optional but may help convert the data to a dictionary.
for depinfo in dependencies: #Looping through the dependency JSON for a single web map
dep_info_list = dependency_recursion(depinfo) #Pulls supporting services out of dependency JSON and adds to list
exp_dependency_dict[key] = dep_info_list #writes keys and values to empty dictionary.
except Exception as e:
print(f'{key} {e}')
# Accounting for edge cases such as maps with no services, experiences with no maps, etc.
for exp, webmap in exp_dependency_dict.items():
if not webmap:
exp_dependency_dict[exp] = {"This Experience has no Supporting Services" : ["Likely no Webmap, Likely no Services"]}
for exp, webmap in exp_dependency_dict.items():
for wmap, service in webmap.items():
if not service:
webmap[wmap] = ["This Webmap has no Supporting Services"]
# Creation of dependency matrix pandas dataframe from dependency dicts
# Could be replaced with the pandas crosstab function
empty_df = pd.DataFrame(dtype = "object")
for exp, webmap in exp_dependency_dict.items():
if webmap:
for wmap, service in webmap.items():
if service:
for serv, fc in service.items():
empty_df.loc[exp, serv] = "x"
empty_df = empty_df.replace(b"", np.nan)
exp_serv_df = empty_df.copy()
exp_serv_df_t = exp_serv_df.transpose()
empty_df = pd.DataFrame(dtype = "object")
for exp, webmap in exp_dependency_dict.items():
if webmap:
for wmap, service in webmap.items():
empty_df.loc[exp, wmap] = "x"
empty_df = empty_df.replace(b"", np.nan)
exp_map_df = empty_df.copy()
exp_map_df_t = exp_map_df.transpose()
writer = pd.ExcelWriter(fr"filepath\AGOL_Dependencies_{formatted_date_mdy}\Feature Class Dependencies.xlsx",
engine='xlsxwriter')
sheet5 = create_new_sheet(writer, exp_fc_df, "Experiences by FC", "Experiences")
sheet6 = create_new_sheet(writer, exp_fc_df_t, "FCs by Experience", "Feature Classes")
writer.close()
writer = pd.ExcelWriter(fr"filepath\AGOL_Dependencies_{formatted_date_mdy}\Feature Service Dependencies.xlsx",
engine='xlsxwriter')
sheet3 = create_new_sheet(writer, exp_serv_df, "Experiences by Service", "Experiences")
sheet4 = create_new_sheet(writer, exp_serv_df_t, "Services by Experience", "Services")
writer = pd.ExcelWriter(fr"filepath\AGOL_Dependencies_{formatted_date_mdy}\Webmap Dependencies.xlsx",
engine='xlsxwriter')
sheet1 = create_new_sheet(writer, exp_map_df, "Experiences by Webmap", "Experiences")
sheet2 = create_new_sheet(writer, exp_map_df_t, "Webmaps by Experience", "Webmaps")
writer.close()
